box_list.h File Reference

Collection of methods to work on Tlist of boxes. More...

#include "list.h"
#include "box.h"
#include "boolean.h"

Functions
void	InitListOfBoxes (Tlist *l)
	Constructor.
void	CopyListOfBoxes (Tlist l_dst, Tlist l_src)
	Copy constructor.
double	ListOfBoxesVolume (boolean used, Tlist l)
	Computes the volume of a list.
double	ListOfBoxesMaxDiagonal (boolean used, Tlist l)
	Computes the maximum diagonal for all boxes in a list.
double	ListOfBoxesMaxSize (boolean used, Tlist l)
	Computes the maximum size for all boxes in a list.
void	ListOfBoxesBB (boolean used, Tbox b, Tlist *l)
	Computes an axis-aligned bounding box for all boxes in a list.
void	ListOfBoxesCluster (boolean used, Tlist l_out, Tlist *l_in)
	Clusters a list of boxes.
void	ConcatListOfBoxes (Tlist l_new, Tlist l)
	Concats two lists.
void	ReverseListOfBoxes (Tlist l_orig, Tlist l)
	Reverses a list.
void	PrintListOfBoxes (FILE f, boolean used, char heading, Tlist l)
	Prints a list of boxes.
boolean	ReadListOfBoxes (char filename, Tlist l)
	Reads a list of boxes from a file.
void	SaveListOfBoxes (FILE f, Tlist l)
	Saves a list of boxes.
void	LoadListOfBoxes (FILE f, Tlist l)
	Loads a list of boxes from a file.
void	DeleteListOfBoxes (Tlist *l)
	Destructor.

Detailed Description

This is a collection of functions working on box lists. A box list is a special list including boxes. This specialization is handy since it facilitates the manipulation of sets of boxes.
It its assumed that all boxes in a list have the same dimensionality. If this is not so, some of the functions implement here will generate errors.

See also:: list.h, box.h, Tlist, Tbox.

Definition in file box_list.h.

Function Documentation

void InitListOfBoxes ( Tlist * l )

Defines an empty list of boxes.

Parameters:

l

The list to create.

Definition at line 24 of file box_list.c.

References InitList().

Referenced by CopyListOfBoxes(), Heap2List(), ListOfBoxesCluster(), LoadListOfBoxes(), ReverseListOfBoxes(), and SampleCuikSystemInBox().

Here is the call graph for this function:

Here is the caller graph for this function:

void CopyListOfBoxes	(	Tlist *	l_dst,
		Tlist *	l_src
	)

Copies one list into another.

The boxes in l_src are duplicated before inserting them into l_dst.

Parameters:

	l_dst	The new list to create.
	l_src	The source list from which to copy.

Definition at line 29 of file box_list.c.

References AddLastElement(), Advance(), CopyBox(), EndOfList(), First(), GetCurrent(), InitIterator(), and InitListOfBoxes().

Here is the call graph for this function:

double ListOfBoxesVolume	(	boolean *	used,
		Tlist *	l
	)

Computes the sum of the volume of the boxes stored in the list.

Parameters:

	used	Array of booleans, one for each interval of the input boxes. If the boolean is TRUE, the corresponding interval is used in the computations. If the given pointer is NULL, all intervals are used.
	l	The list.

See also:: BoxVolume

Definition at line 50 of file box_list.c.

References Advance(), EndOfList(), First(), GetBoxVolume(), GetCurrent(), and InitIterator().

Here is the call graph for this function:

double ListOfBoxesMaxDiagonal	(	boolean *	used,
		Tlist *	l
	)

Computes the maximum diagonal for all the boxes stored in the list.

Parameters:

	used	Array of booleans, one for each interval of the input boxes. If the boolean is TRUE, the corresponding interval is used in the computations. If the given pointer is NULL, all intervals are used.
	l	The list.

See also:: BoxDiagonal

Definition at line 70 of file box_list.c.

References Advance(), EndOfList(), First(), GetBoxDiagonal(), GetCurrent(), and InitIterator().

Here is the call graph for this function:

double ListOfBoxesMaxSize	(	boolean *	used,
		Tlist *	l
	)

Computes the maximum size for all the boxes stored in the list.

Parameters:

	used	Array of booleans, one for each interval of the input boxes. If the boolean is TRUE, the corresponding interval is used in the computations. If the given pointer is NULL, all intervals are used.
	l	The list.

See also:: BoxSize

Definition at line 91 of file box_list.c.

References Advance(), EndOfList(), First(), GetBoxSize(), GetCurrent(), and InitIterator().

Here is the call graph for this function:

void ListOfBoxesBB	(	boolean *	used,
		Tbox *	b,
		Tlist *	l
	)

Computes a box that is an axis-aligned bounding box for all boxes in a list.
This is a box constructor and, therefore box b does not need to be initialized externally before calling this function.
The dimensionality of the output box is that of the boxes in the list.
If the list is empty it returns a dimension-less box.

Parameters:

	used	Array of booleans, one for each interval of the input boxes. If the boolean is TRUE, the corresponding interval is used in the computations. If the given pointer is NULL, all intervals are used.
	b	The output box defining the bounding box for the boxes in the list for the used dimensions.
	l	The list.

See also:: BoxUnion

Definition at line 113 of file box_list.c.

References Advance(), BoxUnion(), CopyBox(), EndOfList(), First(), GetCurrent(), InitBox(), InitIterator(), and ListSize().

Here is the call graph for this function:

void ListOfBoxesCluster	(	boolean *	used,
		Tlist *	l_out,
		Tlist *	l_in
	)

Computes a list of boxes, with one box bounding each one of the connected components defined by the boxes in the input list.
A box is included in a connected component if it has a non-null intersection with one of the boxes already in the component.

Parameters:

	used	Array of booleans, one for each interval of the input boxes. If the boolean is TRUE, the corresponding interval is used in the computations. If the given pointer is NULL, all intervals are used.
	l_out	The output list, with one box for each one of the clusters of the input list.
	l_in	The input list to be clustered.

Definition at line 138 of file box_list.c.

References AddLastElement(), Advance(), BoxesIntersection(), BoxUnion(), CopyBox(), DeleteBox(), EndOfList(), FALSE, First(), GetCurrent(), InitIterator(), InitListOfBoxes(), ListSize(), NEW, and TRUE.

Here is the call graph for this function:

void ConcatListOfBoxes	(	Tlist *	l_new,
		Tlist *	l
	)

Adds l_new at the end of l. We assume l to be properly initialized.

Parameters:

	l_new	The list to add.
	l	The list where to add.

Definition at line 230 of file box_list.c.

References AddLastElement(), Advance(), CopyBox(), EndOfList(), First(), GetCurrent(), and InitIterator().

Here is the call graph for this function:

void ReverseListOfBoxes	(	Tlist *	l_orig,
		Tlist *	l
	)

Reverses the order of a list.

This is a constructor and, thus, l is initialized inside the function.

Parameters:

	l_orig	The list to reverse.
	l	The ouput reversed list.

Definition at line 245 of file box_list.c.

References AddFirstElement(), Advance(), CopyBox(), EndOfList(), First(), GetCurrent(), InitIterator(), and InitListOfBoxes().

Here is the call graph for this function:

void PrintListOfBoxes	(	FILE *	f,
		boolean *	used,
		char *	heading,
		Tlist *	l
	)

Prints a list of boxes to a stream that can be stdout.

Parameters:

	f	The stream where to write.
	used	Array of booleans, one for each interval of the input boxes. If the boolean is TRUE, the corresponding interval is used in the computations. If the given pointer is NULL, all intervals are used.
	heading	A string to be printed before each box. Possibly NULL, in which case nothing is printed. This is used to differentiate list printed in the same file.
	l	The list to be printed.
