statistics.h File Reference

Definition of the Tstatistics type and the associated functions. More...

#include "boolean.h"
#include <time.h>
#include <sys/times.h>
#include <stdio.h>

Data Structures
struct	Tstatistics
	Statistics associated with a solving process. More...
Functions
void	InitStatistics (unsigned int np, double v, Tstatistics *t)
	Constructor.
void	CopyStatistics (Tstatistics t_dst, Tstatistics t_src)
	Copy constructor.
double	GetTime (Tstatistics *t)
	Curent time.
double	GetElapsedTime (Tstatistics *t)
	Elapsed time.
double	GetInitialTime (Tstatistics *t)
	Initial time.
void	SetInitialTime (double tm, Tstatistics *t)
	Sets a new initial time.
void	NewMaxLevel (unsigned int m, Tstatistics *t)
	Sets a new maximum level.
void	NewBoxProcessed (Tstatistics *t)
	Increases the number of processed boxes.
void	NewSolutionBox (boolean validated, double v, double d, Tstatistics *t)
	Increases the number of solution boxes.
void	NewEmptyBox (Tstatistics *t)
	Increases the number of empty boxes.
void	NewSplittedBox (Tstatistics *t)
	Increases the number of splitted boxes.
void	NewRBError (Tstatistics *t)
	Increases the number of errors when reducing a boxe.
void	NewLostBox (Tstatistics *t)
	Increases the number of lost boxes.
void	NewBoxReduction (Tstatistics *t)
	Increases the number of reduced boxes.
unsigned int	GetNBoxReductions (Tstatistics *t)
	Gets the number of reduced boxes.
unsigned int	GetNSolutionBoxes (Tstatistics *t)
	Gets the number of solution boxes.
void	ResetNBoxReductions (Tstatistics *t)
	Resets the number of reduced boxes.
void	AddNBoxReductions (unsigned int nr, Tstatistics *t)
	Increases the number of reduced boxes.
void	PrintStatistics (FILE f, Tstatistics t)
	Prints the statistics to a file.
void	SaveStatistics (FILE f, Tstatistics t)
	Saves the statistics to a file in binary format.
void	LoadStatistics (FILE f, Tstatistics t)
	Loads the statistics from a file in binary format.
void	DeleteStatistics (Tstatistics *t)
	Destructor.

Detailed Description

Module for keeping track of the workings of the CuikSolve process.

See also:: Tstatistics, statistics.c.

Definition in file statistics.h.

Function Documentation

void InitStatistics	(	unsigned int	np,
		double	v,
		Tstatistics *	t
	)

Initializes a set of statistics.

Parameters:

	np	Number of processors.
	v	Volume of the search space.
	t	The statistics to initialize.

Definition at line 21 of file statistics.c.

References GetTime(), Tstatistics::n_box_reductions, Tstatistics::n_empty_boxes, Tstatistics::n_errors, Tstatistics::n_lost_boxes, Tstatistics::n_max_level, Tstatistics::n_processed_boxes, Tstatistics::n_solution_boxes, Tstatistics::n_splitted_boxes, Tstatistics::n_validated_solution_boxes, Tstatistics::np, Tstatistics::s_diagonal, Tstatistics::s_volume, Tstatistics::t_init, and Tstatistics::volume.

Referenced by MPI_SolveCuikSystem(), and SolveCuikSystem().

Here is the call graph for this function:

Here is the caller graph for this function:

void CopyStatistics	(	Tstatistics *	t_dst,
		Tstatistics *	t_src
	)

Initializes a set of statistics fom another set.

Parameters:

	t_dst	The statistics to initialize.
	t_src	The statistics from where to copy.

Definition at line 45 of file statistics.c.

References Tstatistics::n_box_reductions, Tstatistics::n_empty_boxes, Tstatistics::n_errors, Tstatistics::n_lost_boxes, Tstatistics::n_max_level, Tstatistics::n_processed_boxes, Tstatistics::n_solution_boxes, Tstatistics::n_splitted_boxes, Tstatistics::n_validated_solution_boxes, Tstatistics::s_diagonal, Tstatistics::s_volume, Tstatistics::t_init, and Tstatistics::volume.

Referenced by CopyCuikSystem().

Here is the caller graph for this function:

double GetTime ( Tstatistics * t )

Returns the current time. The wayt to get the time is different for single-processor or for multiple-processor environments.

Parameters:

t

The statistics.

Returns:: The current time.

Definition at line 74 of file statistics.c.

References Tstatistics::np.

Referenced by GetElapsedTime(), InitStatistics(), and LoadCSState().

Here is the caller graph for this function:

double GetElapsedTime ( Tstatistics * t )

Returns the time since the statistics where initialized.

Parameters:

t

The statistics to query.

Returns:: The elapsed time.

Definition at line 92 of file statistics.c.

References GetTime(), and Tstatistics::t_init.

Referenced by PostProcessBox(), PrintStatistics(), and SaveCSState().

Here is the call graph for this function:

Here is the caller graph for this function:

double GetInitialTime ( Tstatistics * t )

Returns the time at which the statistics where initialized.

Parameters:

t

The statistics to query.

Returns:: The initialization time.

Definition at line 100 of file statistics.c.

References Tstatistics::t_init.

void SetInitialTime	(	double	tm,
		Tstatistics *	t
	)

Sets a new initial time. This is used when re-starting a process after a crash.

Parameters:

	tm	The new initial time.
	t	The statistics to query.

Definition at line 109 of file statistics.c.

References Tstatistics::t_init.

Referenced by LoadCSState().

Here is the caller graph for this function:

void NewMaxLevel	(	unsigned int	m,
		Tstatistics *	t
	)

Sets a new max level. If the given level is below the stored one nothing is done.

Parameters:

	m	The new maximum level.
	t	The statistics to udpate.

Definition at line 117 of file statistics.c.

References Tstatistics::n_max_level.

Referenced by MPI_SolveCuikSystem(), and SolveCuikSystem().

Here is the caller graph for this function:

void NewBoxProcessed ( Tstatistics * t )

Increases the number of processed boxes.

Parameters:

t

The statistics to update.

Definition at line 126 of file statistics.c.

References Tstatistics::n_processed_boxes.

Referenced by MPI_SolveCuikSystem(), and SolveCuikSystem().

Here is the caller graph for this function:

void NewSolutionBox	(	boolean	validated,
		double	v,
		double	d,
		Tstatistics *	t
	)

Increases the number of solution boxes.

Parameters:

	validated	TRUE if the solution is validated to include a solution point.
	v	Volume of the solution box.
	d	Diagonal of the solution box.
	t	The statistics to update.

Definition at line 134 of file statistics.c.

References Tstatistics::n_solution_boxes, Tstatistics::n_validated_solution_boxes, Tstatistics::s_diagonal, and Tstatistics::s_volume.

Referenced by PostProcessBox().

Here is the caller graph for this function:

void NewEmptyBox ( Tstatistics * t )

Increases the number of empty boxes.

Parameters:

t

The statistics to update.

Definition at line 147 of file statistics.c.

References Tstatistics::n_empty_boxes.

Referenced by PostProcessBox().

Here is the caller graph for this function:

void NewSplittedBox ( Tstatistics * t )

Increases the number of splitted boxes.

Parameters:

t

The statistics to update.

Definition at line 156 of file statistics.c.

References Tstatistics::n_splitted_boxes.

Referenced by PostProcessBox().

Here is the caller graph for this function:

void NewRBError ( Tstatistics * t )

Increases the number of errors when reducing a boxe.

Parameters:

t

The statistics to update.

Definition at line 165 of file statistics.c.

References Tstatistics::n_errors.

Referenced by PostProcessBox().

Here is the caller graph for this function:

void NewLostBox ( Tstatistics * t )

Increases the number of lost boxes.

Parameters:

t

The statistics to update.

Definition at line 173 of file statistics.c.

References Tstatistics::n_lost_boxes.

Referenced by MPI_SolveCuikSystem().

Here is the caller graph for this function:

void NewBoxReduction ( Tstatistics * t )

Increases the number of reduced boxes.

Parameters:

t

The statistics to update.

Definition at line 181 of file statistics.c.

References Tstatistics::n_box_reductions.

Referenced by ReduceBox().

Here is the caller graph for this function:

unsigned int GetNBoxReductions ( Tstatistics * t )

Gets the number of reduced boxes.

Parameters:

t

The statistics to query.

Returns:: The number of reduced boxes up to the moment.

Definition at line 186 of file statistics.c.

References Tstatistics::n_box_reductions.

Referenced by MPI_TreatBox().

Here is the caller graph for this function:

unsigned int GetNSolutionBoxes ( Tstatistics * t )

Gets the number of solution boxes.

Parameters:

t

The statistics to query.

Returns:: The number of solution boxes up to the moment.

Definition at line 191 of file statistics.c.

References Tstatistics::n_solution_boxes.

Referenced by PostProcessBox(), and SolveCuikSystem().

Here is the caller graph for this function:

void ResetNBoxReductions ( Tstatistics * t )

Resets the number of reduced boxes.

Parameters:

t

The statistics to update.

Definition at line 196 of file statistics.c.

References Tstatistics::n_box_reductions.

Referenced by MPI_TreatBox().

Here is the caller graph for this function:

void AddNBoxReductions	(	unsigned int	nr,
		Tstatistics *	t
	)

Increases the number of reduced boxes.

Parameters:

	nr	Number of reduced boxes to add to the current statistis.
	t	The statistics to update.

Definition at line 201 of file statistics.c.

References Tstatistics::n_box_reductions.

Referenced by MPI_SolveCuikSystem().

Here is the caller graph for this function:

void PrintStatistics	(	FILE *	f,
		Tstatistics *	t
	)

Write the statistics sets to a stream that can be stdout. The moment at which the statistics are written is taken as the moment at which the solving process is done.

Parameters:

	f	The stream
	t	The statistics to print.

Definition at line 209 of file statistics.c.

References GetElapsedTime(), Tstatistics::n_box_reductions, Tstatistics::n_empty_boxes, Tstatistics::n_errors, Tstatistics::n_lost_boxes, Tstatistics::n_max_level, Tstatistics::n_processed_boxes, Tstatistics::n_solution_boxes, Tstatistics::n_splitted_boxes, Tstatistics::n_validated_solution_boxes, Tstatistics::np, Tstatistics::s_diagonal, Tstatistics::s_volume, and Tstatistics::volume.

Referenced by MPI_SolveCuikSystem(), and SolveCuikSystem().

Here is the call graph for this function:

Here is the caller graph for this function:

void SaveStatistics	(	FILE *	f,
		Tstatistics *	t
	)

Saves the statistics to a file in binary format. Used to save the internal state of the solver.

Parameters:

	f	The file
	t	The statistics to print.

Definition at line 260 of file statistics.c.

Referenced by SaveCSState().

Here is the caller graph for this function:

void LoadStatistics	(	FILE *	f,
		Tstatistics *	t
	)

Loads the statistics from a file in binary format. Used to retrive the internal state of the solver from a .state file.

Parameters:

	f	The file
	t	The statistics to print.

Definition at line 266 of file statistics.c.

Referenced by LoadCSState().

Here is the caller graph for this function:

void DeleteStatistics ( Tstatistics * t )

Deletes the statistics structure and frees the allocated memory.

Parameters:

t

The statistics to delete.

Definition at line 274 of file statistics.c.

Referenced by DeleteCuikSystem(), and MPI_SolveCuikSystem().

Here is the caller graph for this function:
