vector.c File Reference

Implementation of the functions operating on Tvector. More...

#include "vector.h"
#include "defines.h"
#include <stdlib.h>
#include <string.h>

Functions
boolean	CmpID (void a, void b)
	Comparison operator for identifiers.
void	CopyID (void a, void b)
	Copy constructor for identifiers.
void	DeleteID (void *a)
	Destructor for identifiers.
boolean	CmpDouble (void a, void b)
	Comparison operator for doubles.
void	CopyDouble (void a, void b)
	Copy constructor for doubles.
void	DeleteDouble (void *a)
	Destructor for doubles.
boolean	CmpVoidPtr (void a, void b)
	Comparison operator for void pointers.
void	CopyVoidPtr (void a, void b)
	Copy constructor for void pointers.
void	DeleteVoidPtr (void *a)
	Destructor for void pointers.
void	InitVector (unsigned int ele_size, void(Copy)(void , void ), void(Delete)(void ), unsigned int max_ele, Tvector vector)
	Constructor.
void	ResetVector (Tvector *vector)
	Resets a vector.
void	CopyVector (Tvector v_dst, Tvector v_src)
	Copy constructor.
unsigned int	VectorFirstFreePos (Tvector *vector)
	Finds a free position in the vector.
unsigned int	VectorSize (Tvector *vector)
	Gets the number of elements in a vector.
unsigned int	VectorMaxSize (Tvector *vector)
	Gets the maximum number of elements in a vector.
boolean	VectorEmpty (Tvector *vector)
	Checks if a vector is empty.
boolean	ElementInVector (void e, boolean(cmp)(void , void ), Tvector *vector)
	Search for an element in a vector.
unsigned int	FindPos (void e, boolean(cmp)(void , void ), Tvector *vector)
	Search for an element in a vector.
unsigned int	NewVectorElement (void e, Tvector vector)
	Adds an element to the vector.
unsigned int	NewFreeVectorElement (void e, Tvector vector)
	Adds an element to the vector.
void	SetVectorElement (unsigned int i, void e, Tvector vector)
	Adds an element to the vector in a given position.
void *	GetVectorElement (unsigned int i, Tvector *vector)
	Returns a pointer to a vector element.
void *	GetLastElement (Tvector *vector)
	Returns a pointer to the last element of a vector.
void	RemoveVectorElement (unsigned int i, Tvector *vector)
	Removes an element from the vector.
void	SwapVectorElements (unsigned int i, unsigned int j, Tvector *vector)
	Swaps two elements in a vector.
void	ExtractVectorElement (unsigned int i, void e, Tvector vector)
	Extracts an element from a vector.
void	MoveVectorElement (unsigned int i, unsigned int ni, Tvector *vector)
	Moves a vector element from one position to another.
void	DeleteVector (void *vector)
	Destructor.

Detailed Description

Implementation of the functions operating on Tvector.

See also:: Tvector,vector.h,

Definition in file vector.c.

Function Documentation

boolean CmpID	(	void *	a,
		void *	b
	)

Comparison operator for identifiers. To be used when defining a vector of identifiers (i.e., unsigned int).

Parameters:

	a	Pointer to the first identifier to compare.
	b	Pointer to the second identifier to compare.

Returns:: TRUE if the two inputs are the same.

Definition at line 19 of file vector.c.

void CopyID	(	void *	a,
		void *	b
	)

Copy constructor for identifiers. To be used when defining a vector of identifiers (i.e., unsigned int). This is a direct assignation.

Parameters:

	a	Pointer to the identifier to initialize.
	b	Pointer to the identifier from where to copy.

Definition at line 24 of file vector.c.

Referenced by InitHeap().

Here is the caller graph for this function:

void DeleteID ( void * a )

Destructor for identifiers. To be used when defining a vector of identifiers (i.e., unsigned int). This basically frees the space taken by the identifier.

Parameters:

a

Pointer to the identifier to delete.

Definition at line 29 of file vector.c.

Referenced by InitHeap().

Here is the caller graph for this function:

boolean CmpDouble	(	void *	a,
		void *	b
	)

Comparison operator for doubles. To be used when defining a vector of doubles.

Parameters:

	a	Pointer to the first double to compare.
	b	Pointer to the second double to compare.

Returns:: TRUE if the two inputs are the same.

Definition at line 34 of file vector.c.

void CopyDouble	(	void *	a,
		void *	b
	)

Copy constructor for doubles. To be used when defining a vector of doubles. This is a direct assignation.

Parameters:

	a	Pointer to the double to initialize.
	b	Pointer to the double from where to copy.

Definition at line 39 of file vector.c.

void DeleteDouble ( void * a )

Destructor for doubles. To be used when defining a vector of doubles. This basically frees the space taken by the double.

Parameters:

a

Pointer to the double to delete.

Definition at line 44 of file vector.c.

boolean CmpVoidPtr	(	void *	a,
		void *	b
	)

Comparison operator for doubles. To be used when defining a vector of pointers.

Parameters:

	a	Pointer to the first pointer to compare.
	b	Pointer to the second pointer to compare.

Returns:: TRUE if the two inputs are the same.

Definition at line 49 of file vector.c.

void CopyVoidPtr	(	void *	a,
		void *	b
	)

Copy constructor for doubles. To be used when defining a vector of pointers. This is a direct assignation.

Parameters:

	a	Pointer to the pointer to initialize.
	b	Pointer to the pointer from where to copy.

Definition at line 54 of file vector.c.

Referenced by CopyLink(), CreateBranch(), GenerateKinTree(), InitLink(), and InitMechanism().

Here is the caller graph for this function:

void DeleteVoidPtr ( void * a )

Destructor for void pointers. To be used when defining a vector of pointers. This basically frees the space taken by the pointer.

Parameters:

a

Pointer to the pointer to delete.

Definition at line 59 of file vector.c.

Referenced by CopyLink(), CreateBranch(), GenerateKinTree(), InitLink(), and InitMechanism().

Here is the caller graph for this function:

void InitVector	(	unsigned int	ele_size,
		void()(void , void *)	Copy,
		void()(void )	Delete,
		unsigned int	max_ele,
		Tvector *	vector
	)

Initializes an empty vector Examples of use:

InitVector(sizeof(unsigned int),CopyID,DeleteID,MaxNumEle,&vector);
InitVector(sizeof(double),CopyDouble,DeleteDouble,MaxNumEle,&vector);
InitVector(sizeof(void *),CopyPtr,DeletePtr,MaxNumEle,&vector);

Parameters:

	ele_size	Number of bytes taken by each element in the list.
	Copy	Copy constructor for the elements in the list.
	Delete	Destructor for the elements in the list.
	max_ele	Initial number of elements in the vector. This can be extended on-line but the execution it is more efficient if we have a good guess for this value.
	vector	The vector to initialize.

Definition at line 67 of file vector.c.

References Tvector::Copy, Tvector::Delete, Tvector::ele_size, Tvector::elements, Tvector::max_ele, NEW, and Tvector::num_ele.

Referenced by CopyLink(), CreateBranch(), GenerateKinTree(), InitHeap(), InitLink(), and InitMechanism().

Here is the caller graph for this function:

void ResetVector ( Tvector * vector )

Removes all the elements from a vector but it does not frees the allocated memory nor resets the maximum number of elements. If you plan to re-use a vector it is more efficient to reset it instead of deleting it and re-initializing it again.

Parameters:

vector

The vector to reset.

Definition at line 83 of file vector.c.

References Tvector::Delete, Tvector::elements, and Tvector::num_ele.

Referenced by DeleteVector(), and ResetHeap().

Here is the caller graph for this function:

void CopyVector	(	Tvector *	v_dst,
		Tvector *	v_src
	)

Initializes a vector from another vector.

Parameters:

	v_dst	The vector to initialize.
	v_src	The vector from where to copy.

Definition at line 101 of file vector.c.

References Tvector::Copy, Tvector::Delete, Tvector::ele_size, Tvector::elements, Tvector::max_ele, NEW, and Tvector::num_ele.

Referenced by CopyHeap().

Here is the caller graph for this function:

unsigned int VectorFirstFreePos ( Tvector * vector )

Returns the first (i.e., with lower identifier) free position in a vector.

Parameters:

vector

The vector to query.

Returns:: The index of the free position.

Definition at line 125 of file vector.c.

References Tvector::elements.

Referenced by NewFreeVectorElement().

Here is the caller graph for this function:

unsigned int VectorSize ( Tvector * vector )

Returns the number of elements in a vector. Note that the vector can have "holes", i.e., empty slots in position explicitly deleted using RemoveVectorElement.

Parameters:

vector

The vector to query.

Returns:: The number of elements in the vector.

See also:: RemoveVectorElement

Definition at line 136 of file vector.c.

References Tvector::num_ele.

Referenced by GetMechanismNJoints(), GetMechanismNLinks(), InitWorldKinCS(), LinkNBodies(), and nStepsBranch().

Here is the caller graph for this function:

unsigned int VectorMaxSize ( Tvector * vector )

Returns the maximum number of elements in a vector. Note that the vector can have "holes", i.e., empty slots in position explicitly deleted using RemoveVectorElement.

Parameters:

vector

The vector to query.

Returns:: The maximum number of elements in the vector.

Definition at line 141 of file vector.c.

References Tvector::max_ele.

boolean VectorEmpty ( Tvector * vector )

Checks if a vector is empty

Parameters:

vector

The vector to query.

Returns:: TRUE if there are no elements in the vector.

Definition at line 146 of file vector.c.

References Tvector::num_ele.

boolean ElementInVector	(	void *	e,
		boolean()(void , void *)	cmp,
		Tvector *	vector
	)

Looks for an element in a vector.

Parameters:

	e	The element we are looking for.
	cmp	The comparison operator to use to determine if two elements are the same. Note that for structured types the comparison can be based on a particular field and that only those field need to be initialized in parameter e.
	vector	The vector to query.

Returns:: TRUE if the vector includes the requested element.

Definition at line 151 of file vector.c.

References FindPos().

Here is the call graph for this function:

unsigned int FindPos	(	void *	e,
		boolean()(void , void *)	cmp,
		Tvector *	vector
	)

Looks for an element in a vector.

Parameters:

	e	The element we are looking for.
	cmp	The comparison operator to use to determine if two elements are the same. Note that for structured types the comparison can be based on a particular field and that only those field need to be initialized in parameter e.
	vector	The vector to query.

Returns:: The position in the vector holding the requested element or NO_UINT if the vector does not include the element.

Definition at line 156 of file vector.c.

References Tvector::elements, FALSE, and TRUE.

Referenced by ElementInVector().

Here is the caller graph for this function:

unsigned int NewVectorElement	(	void *	e,
		Tvector *	vector
	)

Adds an element at the end of the list.

Parameters:

	e	The element add to the vector.
	vector	The vector to update.

Returns:: The position in the vector where the element has been stored.

Definition at line 179 of file vector.c.

References Tvector::num_ele, and SetVectorElement().

Referenced by AddBody2Link(), AddStepToBranch(), and GenerateKinTree().

Here is the call graph for this function:

Here is the caller graph for this function:

unsigned int NewFreeVectorElement	(	void *	e,
		Tvector *	vector
	)

Looks for a free vector position and stores the given element.

Parameters:

	e	The element add to the vector.
	vector	The vector to update.

Returns:: The position in the vector where the element has been stored.

Definition at line 190 of file vector.c.

References SetVectorElement(), and VectorFirstFreePos().

Here is the call graph for this function:

void SetVectorElement	(	unsigned int	i,
		void *	e,
		Tvector *	vector
	)

Adds an element to the vector in a given position. If the vector position was already occupied, the stored element is deleted before copying the new element.

Parameters:

	i	The vector position where to store the element.
	e	The element add to the vector.
	vector	The vector to update.

Definition at line 201 of file vector.c.

References Tvector::Copy, Tvector::Delete, Tvector::ele_size, Tvector::elements, Tvector::max_ele, MEM_EXPAND, NEW, and Tvector::num_ele.

Referenced by AddElement2Heap(), AddJoint2Mechanism(), AddLink2Mechanism(), NewFreeVectorElement(), and NewVectorElement().

Here is the caller graph for this function:

void* GetVectorElement	(	unsigned int	i,
		Tvector *	vector
	)

Returns a pointer to a given vector element.

Parameters:

	i	The vector position to retrive.
	vector	The vector to query.

Returns:: A pointer to the requested vector element or NULL if the vector position i is free.

Definition at line 236 of file vector.c.

References Tvector::elements.

Referenced by DeleteBranch(), DistanceToSubBoxCenter(), ExtractMinElement(), GetBranchStep(), GetHeapElement(), GetHeapPosition(), GetLinkBody(), GetMechanismJoint(), GetMechanismLink(), HeapDown(), HeapUp(), InitWorldKinCS(), PointInSubBox(), and PointInSystemBox().

Here is the caller graph for this function:

void* GetLastElement ( Tvector * vector )

Returns a pointer to a the last element of a vector.

Parameters:

vector

The vector to query.

Returns:: A pointer to the last element of the vector.

Definition at line 244 of file vector.c.

References Tvector::elements, and Tvector::num_ele.

void RemoveVectorElement	(	unsigned int	i,
		Tvector *	vector
	)

Removes an element from the vector. Note that elements in the vector are not compacted after the deletion. In this way indexes in other data structured refered to this vector still hold after the deletion. The drawnback is that we can end up with a vector with "holes" and we have to be carefull when retriving elements from the vector.

Parameters:

	i	The vector position to delete.
	vector	The vector to query.

Definition at line 252 of file vector.c.

References Tvector::Delete, Tvector::elements, and Tvector::num_ele.

Referenced by ExtractMinElement(), ExtractVectorElement(), and MoveVectorElement().

Here is the caller graph for this function:

void SwapVectorElements	(	unsigned int	i,
		unsigned int	j,
		Tvector *	vector
	)

Swaps two elements in a vector. This operation is provided since it is more efficient than extracting the two elements and then inserting them again in the vector in their new positions.

If one of the two elements to swap is empty, this function triggers an error.

Parameters:
